• CERTIFIED MODULAR ENCLOSURE
Explosion Protection for Technology
ExBox® is a patented certified enclosure
(CZ 308042, CZ 310739) for housing electrical installations in explosive atmospheres.
Developed and manufactured by
ATHEX Technology Ltd., Zlín, Czech Republic.
Its modular ALU construction is designed for ATEX environments (Zones 2/22 and 1/21), with IP68 / IP69, IK10, range of −40 to +70 °C.
Unlike standard enclosures, ExBox protects sensitive technology where explosion risk, dust, moisture and extreme temperatures are present. One certified enclosure replaces several single-purpose solutions. 20-year aluminium guarantee.
ExBox
®
Engineered • Certified • Guaranteed
130years
Years of Proven Principle
75%
Lighter Than Standard 100 kg Steel Enclosures
25%
Less Equipment Required
20years
Service Guarantee for Aluminum ExBox.
• SYSTEM BASE
ExBox UNI
The foundation is a certified aluminium enclosure with a flameproof closure "d" — a sealed construction for the safe housing of electrical installations in Ex environments. Using the system configurator, it extends into product lines and custom configurations.
• Optimised thin-wall aluminium casting
• Corrosion-resistant stainless-steel mechanical joints
• IP68/IP69 protection and IK10 impact resistance
• Ex-certified cable and connector interfaces
• Modular EBS / EBD system
• Servicing by personnel authorised by the equipment owner
ExBox Single - EBS
400 × 500 × 154 mm • 11,5 kg • 8,2 l
ExBox Double - EBD
688 × 500 × 164 mm • 19,5 kg • 16,4 l
One certified enclosure • Multiple technologies • Reduced certification burden
• PROOF
75% lighter than the steel alternative
The same level of protection at a fraction of the weight. A standard steel solution weighs around 100 kg and requires lifting equipment.
Standard solution
ExBox
25 kg
Lower weight enables installation without lifting equipment, reduces load-bearing structure requirements, and lowers transport and on-site servicing costs.
100 kg
ExBox benefits
01
Flameproof Enclosure “d”
A protection principle that prevents an internal explosion from propagating into the surrounding atmosphere, proven through more than 130 years of use. ExBox integrates this established safety principle into a modern die-cast aluminium enclosure.
02
Consolidate operational requirements into a single repository
Operations and maintenance across industries address the same challenges – certification, installation, service, downtime and future technology upgrades. ExBox unifies them into one certified repository, delivering simpler management and lower costs throughout the lifecycle.
03
Service and System Guarantee
A 20-year guarantee on the ExBox aluminium enclosure, long-term service support and modular component replacement ensure fast servicing, minimal downtime and reliable operation throughout its entire lifecycle.
04
Modularity and Integration
ExBox integrates lighting, cameras, communication systems and other industrial electronics from trusted global manufacturers. The internal technology can be upgraded or replaced throughout its lifecycle without replacing the certified enclosure.
05
Durable Aluminium Construction
The patented die-cast aluminium construction combines high mechanical resistance, low weight and a long service life. Its recyclable material supports efficient use of resources throughout the entire lifecycle.
• PRODUCT LINES
ExBox Variants
One Certified Enclosure + Configurator = Dozens of Applications. Hundreds of Variants.
ExBox UNI
Certified Base Enclosure · Patent CZ 308042 · Die-Cast Aluminium ·
CE · IP68 / IP69 · IK10 · +75 °C · ATEX Timeline & Details
* Patent CZ 310739 for ExBox Lighting module
ExBox LIGHTING
ExBox EMERGENCY LIGHTING
ExBox MONITORING
ExBox - Single - Lighting
EBS L
ExBox - Single - Emergency
EBS L EM
ExBox - Single - MONITORING
EBS M
PRODUCT LINE
• CUSTOM-ENGINEERED SOLUTIONS
• CERTIFICATION
Industrial standards
Specifications available upon request / under NDA
CE
IP68
IP69
IK10
+75°C
ATEX
2/22 · 1/21
• OPERATING ENVIRONMENTS
EX
Explosive Environments
Target Classification (Timeline & Details)
GASES & DUST
II 2G Ex d IIB+H2 T6 Gb
II 2D Ex tb IIIB T100 °C Db IP68
II 3G Ex nR IIB+H2 T6 Gb
II 3D Ex tb IIIB T100 °C Db IP68
IND
Industrial Environments
Heavy industry, metallurgy, petrochemicals, food processing, and pharmaceuticals.
Explosive Environments
HT
High Temperatures 70 °C +
Continuous operating temperatures exceeding 70°C. Steel mills, foundries, power generation facilities.
Explosive Environments
EM
Emergency
Emergency Lighting and Evacuation Systems
For Ex and industrial environments.
• SPECIFICATIONS
Technical parameters
Material
Closure
Fasteners
Protection Rating
Impact Resistance
Temperature
Ex Classification
Aluminum Alloy · Die Casting
Tight „d" · IEC/EN 60079-1
Stainless Steel · Corrosion-Resistant
IP65 – IP69
IK10
−40 °C up to +70 °C
Zone I / II · ATEX Timeline & Details
EBS Dimensions
EBS Weight
EBD Dimensions
EBD Weight
Warranty
Patents
Certifications
400 × 500 × 154 mm
11,5 kg · 8,2 l internal volume
688 × 500 × 164 mm
19,5 kg · 16,4 l internal volume
20 let · Unit-for-unit replacement
CZ 308042 · CZ 310739
Available upon request
